Pagefast is a textured finish, poly methyl methacrylate, trowel applied, colour quartz, decorative floor screed. The slip-resistant properties are achieved through the use of mineral and quartz aggregates and can be tailored to suit project-specific requirements.

Download PDF Brochure

The Pagefast range was developed specifically for the industrial flooring market and is used predominantly in the Food, Drinks, Hospitality and Automotive sectors. It has a certified anti-skid rating in accordance with BS 7976-2:2002 ensuring that the safety of your customers and staff is paramount as the risk of trips, slips and other accidents are reduced.



  • Monolithic seamless surface
  • High aesthetics with a vast range of colours
  • Textured
  • Low maintenance
  • High abrasion resistance
  • UV resistant
  • Hygienic
FeRFA Resin Flooring guidelines

Floor seal

Description:

Applied in two or more coats. Generally solvent or water borne.

Duty:

light foot traffic, occasional rubber tyred vehicles.

Typical Thickness:

up to 150 µm

Floor coating

Description:

Applied in two or more coats. Generally solvent free.

Duty:

light foot traffic, occasional rubber tyred vehicles/regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys

Typical Thickness:

150 µm to 300 µm

High build floor coating

Description:

Applied in two or more coats. Generally solvent or water borne.

Duty:

lregular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys

Typical Thickness:

300 µm to 1000 µm

Multi-layer flooring

Description:

Aggregate dressed systems based on multiple layers of floor coatings or flow-applied floorings, often described as ‘sandwich’ systems.
MD/HD

Duty:

regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys/constant fork lift truck traffic, hard plastic wheeled trolleys, some impact

Typical Thickness:

> 2 mm

Flow applied flooring

Description:

Often referred to as ‘self-smoothing’ or ‘self-levelling’ flooring and having a smooth surface.

Duty:

regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys/constant fork lift truck traffic, hard plastic wheeled trolleys, some impact

Typical Thickness:

2 mm to 3 mm

Resin screed flooring

Description:

Trowel-finished, heavily filled systems, generally incorporating a surface seal coat to minimize porosity.

Duty:

regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys/constant fork lift truck traffic, hard plastic wheeled trolleys, some impact

Typical Thickness:

> 4 mm

Heavy duty flowable flooring

Description:

Having a smooth surface.

Duty:

constant fork lift truck traffic, hard plastic wheeled trolleys, some impact/severe heavily loaded traffic and impact

Typical Thickness:

4 mm to 6 mm

Heavy duty resin flooring

Description:

Trowel-finished, aggregate filled systems effectively impervious throughout their thickness.

Duty:

severe heavily loaded traffic and impact

Typical Thickness:

> 6 mm

Spec.

Preparation

Remove all laitance, contaminants, traces of dirt and grease from the substrate and ensure that it is dry. Approved preparation methods are shot blasting, scabbling or diamond grinding, the method selected should be appropriate for the substrate.

Installation

Install Page trowel applied decorative screed to 4mm thickness, priming surface with a Page V proprietary priming resin, basecoat consisting of Page C21S resin and coloured quartz and seal with 2 no. coats of Page T31R; all in accordance with the manufacturer’s instructions.

Application

Application Stages

Prepare the substrate

Prime using a Page proprietary priming resin (see data sheets) @ 0.40kg/m2

Install the base coat at a nominal 4mm using Page C21S resin (see data sheet) and coloured quartz

Before the base coat has cured, fully broadcast with coloured quartz (size 0.7-1.2mm) or a combination of coloured quartz (size 0.7-1.2mm) and mineral aggregate (size 1.0-1.4mm).

Apply 2 no. top coats of Page T31R top coat resin (see data-sheet) @ 0.35 kg/m2 (per coat)

Areas Of Application

For moderate to high mechanical stresses

Slip resistant coating for permanently or occasionally wet areas

Indoor use only

Substrate

Cementitious substrates must be sound, dry and free of laitance, loose particles, oil, dust, grease and contaminants which could cause future delamination. It should have a compressive strength > 25 N/mm2, a cohesive strength > 1.5 N/mm2 and moisture content < 5.0%.
Pagefast systems are designed to follow the contours of the existing concrete substrate, therefore there cannot be any sudden irregularities, undulations or high spots.

We have a range of primers designed for application on various substrates such as wood, steel, ceramic & quarry tiles, terrazzo and indoor asphalt. Please contact our technical department.

Aftercare

Refer to Page’s Cleaning Manual.

Chemical spillages should be dealt with immediately to prevent staining or damage.

Life Expectancy

Greater than 10 years, subject to correct maintenance regime.

Properties

Monolithic seamless surface
High aesthetics with a vast range of colours
Textured
Low maintenance
High abrasion resistance
UV resistant
Hygienic

Technical Data

Texture: Textured

Finish: Semi-gloss

Thickness: 4mm

Curing time: Full chemical cure – 1 hour Compressive strength: 45 N/mm2 -DIN1164 Tensile strength:29 N/mm2 – DIN1164

Slip resistance PTV 72 (dry)

BS 7976-2:2002

PTV 60 (wet)

BS 7976-2:2002

Chemical resistance: Refer to Page PMMA Chemical Resistance Chart Temperature resistance:+60oC (+80oC for short irregular periods e.g. wash-downs)

Abrasion resistance: Class AR1 Heavy duty
